Product Description

Shallow, Single Gang, Semi Adjustable Die Cast Aluminum Box

The Lew Electric SH-1101-DA is a single gang, die cast aluminum concrete floor box. The box offers 1″ of adjustability before installation and has no adjustment after installation. The shallow construction makes it perfect for concrete installations of 2.5″ to 3″ in depth. There are (4) 3/4″ knockouts on the box (one on each side), and it ships with a protective cement cover. There is no tile frame included. Tile frame part number 1101-DBE-B (brass) or 1101-DBE-A (aluminum) is required to complete installation. The box is UL listed for the USA, and CSA listed for Canada installations.

Additional Images

Specifications

• Dimensions: SEE BELOW
• Adjust before: 1″ / Interior Capacity: 15.5 cu. in
• Openings: Sides (4) 3/4″
• Top: NO TOP (1101-DBE-B or 1101-DBE-A required)
• Requires cover, sold separately
• For concrete installations of 2.5″ to 3″ depth
• 1″ of adjustability before installation
• Includes construction cap
• Includes cover screws to secure to box
• Box dimensions as sold: H: 1.56 L: 4.25 W: 3.375
• Box dimensions with 1101-DBE tile frame (required): H: 2.3125 L: 4.25 W: 3.375
• Can be used with carpet or tile
• Warranty: 1 year

Drawings and Resources

Certifications and Compliances

• ETL listed under UL standard 514A and CSA standard C22.2 #18.1.
• ETL FILE NUMBER: 4004534
