Countertop Spill Proof Pop Up 20A GFI Outlet & Charging USB, Black The Lew Electric PUR20-BK-GFI-2USB is a spill proof countertop pop up retractable power outlet that hides in your kitchen countertops. Press the top and pull up the outlet to gain a




  • Share this product:
  •
  •
  • Product Description

    Countertop Spill Proof Pop Up 20A GFI Outlet & Charging USB, Black

    The Lew Electric PUR20-BK-GFI-2USB is a spill proof countertop pop up retractable power outlet that hides in your kitchen countertops. Press the top and pull up the outlet to gain access to the power plugs and USB charging ports. When not in use, the unit hides out of the way under your counter. The circular top is a durable stainless steel, perfect for matching appliances, and nickel fixtures in your kitchen.

    Meets NEC Electrical Code 406.5E for Installation in Countertops

    The pop up meets code for kitchen and wet location installations in counters, it is compliant to National Electrical Code (NEC) 406.5E for countertop use in the USA and Canada. The outlet has tamper proof plugs and is UL listed, the pop up as a complete unit is ETL listed for USA installations, and cETL and CSA approved for Canadian installations. The top has passed UL’s spill proof rating.

    Waterproof Protection Against Liquids

    The top features the highest water protection of any pop up on the market, it has achieved an industry leading IP54 spill proof rating from UL laboratories. In the closed position the top is waterproof, a seamless top keeps watering from entering the pop up. In the open position, the electrical outlet has passed UL’s 8oz spill test. A gasket on the bottom of the pop up keeps spilled liquid from entering into the hole in the counter, and keeping liquid from entering into your cabinets.

    The Only GFCI 20A Pop Up with USB Charging Ports on the Market

    The outlet is 20 Amp rated allowing you to plug in the most power hungry small appliances. You can also insert 15 Amp plugs into the 20 Amp outlet. The outlet has integrated GFCI protection providing safety right at the source, if the outlet recognizes an unsafe interruption in the current, it will automatically shut off power to the outlet. The USB ports are rated for 3.6 Amps of shared power. There is a smart chip inside the outlet making the USB intelligent charging ports. They will automatically adapt to the device being plugged in, and send the maximum amount of power that the device can handle, ensuring that your device won’t be over-charged. The outlet is weather resistant (WR) and has passed UL’s 8oz spill test. The plugs are tamper resistant (TR) ensuring you meet code, and offer the peace of mind knowing that little lids can’t put any small objects in the outlet, and electrocute themselves.

    Cut Your Hole and Plug it in, Easy Installation

    This pop up couldn’t be any easier to install, and only needs a 3.75” round hole to be cut in your countertop. After you drop the unit in the hole, secure to the underside of your counter with the included threaded flange. To supply power to the pop up and USB charging ports, simply plug the end of the 9’ cord into a 20 amp outlet. A single cord provides power to both the outlet, and the USB charging ports. Lastly, install the included trim ring (if desired), and you have completed installation.

    Retractable Power Solution for Kitchen Worktops

    The Lew Electric PUR20-BK-GFI-2USB is perfect for any countertop location, as well as kitchen islands. It can also be used in any other potentially wet locations that requires recessed power such as pantries, airports, restaurants, bars, and hotels. Use the pop up to power small appliances such as coffee makers, blenders, toaster ovens, and warming trays. It can also be used for charging mobile devices such as tablets and phones through the USB ports. The pop up can be installed in granite, quartz, marble, wood, laminate, concrete, or any surface up to 2 3/16” thick, that you can cut the required 3.75” hole.

    Get power exactly where you need in your counter, while meeting code with your electrical inspector. Keep dangerous cords from hanging over the sides of counters, with an in-counter pop up outlet.

    Additional Images

    Specifications

    Color:  Black top with chrome trim Black outlet:  20 Amp GFCI Tamper resistant (TR) plugs USB:  (2) Smart charging 2.1 Amp ports Weather resistant (WR) outlet Meets 2014 NEC code 406.5E for countertops ETL listed for USA installations, # 4004534 cETL listed for Canada installation, # 4004534 CSA approved for Canada, #C22.2 Conforms to UL 514A and 498 UL listed receptacle, # E60120 Water protection:  IP 54 Spill proof rated Gasket under bezel to keep water out Bezel size:  4 7/8” round Cutout size:  3 3/4” round Pop up height: 7.5″ Depth under 3cm counter:  10.5″ Works in counter thickness: 3/8” – 2 3/16”  Flange width needed under counter: 4 15/16″ 9’ corded 3 prong 20A plug  Must be plugged into a 20A outlet Install using a licensed electrician Consult with electrician/inspector before ordering  Designed for indoor installations only Includes trim ring RoHS and Proposition 65 compliant 1 year warranty

    Drawings and Resources

    Adobe PDF: Download
    AutoCAD DWG:
    Install Instructions: Download

    Certifications and Compliances
